LPC546xx
NXP Semiconductors
32-bit ARM Cortex-M4 microcontroller
10. Static characteristics
10.1 General operating conditions
Table 12. General operating conditions
Tamb = 40 C to +105 C, unless otherwise specified.
Symbol
Parameter
Conditions
Min
-
Typ[1]
Max
220
220
Unit
MHz
MHz
[3]
[3]
fclk
CPU clock frequency
CPU clock frequency
-
-
For USB high-speed device and
host operations
60
[3]
CPU clock frequency
For USB full-speed device and host
operations
12
-
220
MHz
For OTP programming only
-
-
-
-
-
-
-
-
12
MHz
V
VDD
supply voltage (core
and external rail)
1.71
2.7
3.0
1.71
1.71
2.0
3.6
3.6
3.6
3.6
3.6
VDDA
[2]
For OTP programming only
For USB operation only
V
V
VDDA
VBAT
Vrefp
analog supply voltage
battery supply voltage
V
V
ADC positive reference VDDA 2 V
V
voltage
VDDA < 2 V
VDDA
-
-
VDDA
+85
V
Tamb
Temperature
For EEPROM operation
40.0
C
RTC oscillator pins
Vi(rtcx) 32.768 kHz oscillator
on pin RTCXIN
-0.5
-0.5
-
-
+3.6
+3.6
V
V
input voltage
Vo(rtcx)
32.768 kHz oscillator
output voltage
on pin RTCXOUT
Vi(xtal)
crystal input voltage
crystal output voltage
on pin XTALIN
0.5
0.5
-
-
1.95
1.95
V
V
Vo(xtal)
on pin XTALOUT
[1] Typical ratings are not guaranteed. The values listed are for room temperature (25 C), nominal supply voltages.
[2] Attempting to program below 2.7 V will result in unpredictable results and the part might enter an unrecoverable state.
[3] The LPC5460x/61x operates at CPU frequencies of up to 180 MHz. The LPC54628 operates at CPU frequencies of up to 220 MHz.
10.2 Power-up ramp conditions
Table 13. Power-up characteristics[1]
Tamb = 40 C to +105 C.
Symbol
Parameter
Min
Typ
Max
Unit
twd
Window duration
-
-
170
s
(time where
V1<VDD<V2)
[2]
[3]
V1
V2
Window low voltage
Window high voltage
1.4
-
-
-
-
V
V
1.62
[1] Assert the external reset pin until VDD is > 1.62 V if the power-up characteristic specification cannot be
implemented.
[2]
VDD to stay above V1 for the entire duration twd.
