LPC2212/2214
NXP Semiconductors
16/32-bit ARM microcontrollers
002aad148
200
I
DD(pd)
(µA)
1.95 V
1.8 V
160
120
80
1.65 V
40
0
-40
-15
10
35
60
85
temperature (°C)
Test conditions: Power-down mode entered executing code from on-chip flash.
Fig 13. Typical LPC2212/01 and LPC2214/01 core power-down current IDD(pd) measured at different temperatures
Table 8.
Typical LPC2212/01 and LPC2214/01 peripheral power consumption in active
mode
Core voltage 1.8 V; Tamb = 25 °C; all measurements in µA; PCLK = CCLK⁄4.
Peripheral
Timer0
Timer1
UART0
UART1
PWM0
I2C-bus
SPI0/1
RTC
CCLK = 12 MHz
CCLK = 48 MHz
CCLK = 60 MHz
43
46
98
103
103
9
141
150
320
351
341
37
184
180
398
421
407
53
6
27
29
16
33
306
55
78
ADC
128
994
167
1205
EMC
LPC2212_2214_4
© NXP B.V. 2008. All rights reserved.
Product data sheet
Rev. 04 — 3 January 2008
35 of 45
