LPC2212/2214
NXP Semiconductors
16/32-bit ARM microcontrollers
002aad146
45
60 MHz
48 MHz
I
DD(act)
(mA)
35
25
15
5
12 MHz
-40
-15
10
35
60
85
temperature (°C)
Test conditions: Active mode entered executing code from on-chip flash; PCLK = CCLK⁄4;
core voltage 1.8 V; all peripherals disabled.
Fig 11. Typical LPC2212/01 and LPC2214/01 IDD(act) measured at different temperatures
002aad147
6.0
I
DD(idle)
(mA)
5.0
4.0
3.0
2.0
1.0
60 MHz
48 MHz
12 MHz
-40
-15
10
35
60
85
temperature (°C)
Test conditions: Idle mode entered executing code from on-chip flash; PCLK = CCLK⁄4;
core voltage 1.8 V; all peripherals disabled.
Fig 12. Typical LPC2212/01 and LPC2214/01 IDD(idle) measured at different temperatures
