LPC2212/2214
NXP Semiconductors
16/32-bit ARM microcontrollers
002aad145
8
I
DD(idle)
(mA)
60 MHz
48 MHz
6
4
2
0
12 MHz
1.65
1.80
1.95
voltage (V)
Test conditions: Idle mode entered executing code from on-chip flash; PCLK = CCLK⁄4;
Tamb = 25 °C; core voltage 1.8 V; all peripherals enabled.
Fig 9. Typical LPC2212/01 and LPC2214/01 IDD(idle) measured at different voltages
002aad144
8
I
DD(idle)
(mA)
60 MHz
48 MHz
6
4
2
0
12 MHz
1.65
1.80
1.95
voltage (V)
Test conditions: Idle mode entered executing code from on-chip flash; PCLK = CCLK⁄4;
Temp = 25 °C; core voltage 1.8 V; all peripherals disabled.
Fig 10. Typical LPC2212/01 and LPC2214/01 IDD(idle) measured at different voltages
