Nexperia
PMPB47XP
30 V, single P-channel Trench MOSFET
017aaa895
-3
-2
-1
0
I
S
(A)
T = 150 °C
j
T = 25 °C
j
0
-0.2
-0.4
-0.6
-0.8
V
-1.0
(V)
SD
VGS = 0 V
Fig. 16. Source current as a function of source-drain voltage; typical values
8. Test information
t
t
1
2
P
duty cycle δ =
t
2
t
1
t
006aaa812
Fig. 17. Duty cycle definition
9. Package outline
0.51
0.61
0.2
0.3
0.2
0.3
3
4
5
6
0.25
0.35
1.9
2.1
2
1
1.0
1.2
1.1
1.3
0.65
1.9
2.1
Dimensions in mm
12-04-30
Fig. 18. Package outline DFN2020MD-6 (SOT1220)
©
PMPB47XP
All information provided in this document is subject to legal disclaimers.
Nexperia B.V. 2017. All rights reserved
Product data sheet
5 December 2012
9 / 14
