PMBT3904YS
40 V, 200 mA NPN/NPN general-purpose double transistor
12. Soldering
2.65
solder lands
0.4 (2×)
1.5
2.35
0.6
(4×)
0.5
(4×)
solder resist
solder paste
0.5
(4×)
0.6
(2×)
occupied area
0.6
(4×)
Dimensions in mm
1.8
sot363_fr
Fig. 9. Reflow soldering footprint for TSSOP6 (SOT363)
1.5
solder lands
solder resist
occupied area
2.5
0.3
4.5
1.5
Dimensions in mm
preferred transport
direction during soldering
1.3
1.3
2.45
5.3
sot363_fw
Fig. 10. Wave soldering footprint for TSSOP6 (SOT363)
©
