PBSS8110X
NXP Semiconductors
100 V, 1 A NPN low VCEsat (BISS) transistor
9. Package outline
4.6
4.4
1.8
1.4
1.6
1.4
2.6
2.4
4.25
3.75
1.2
0.8
1
2
3
0.53
0.40
1.5
0.48
0.35
0.44
0.23
3
Dimensions in mm
06-08-29
Fig 18. Package outline SOT89 (SC-62/TO-243)
10. Packing information
Table 8.
Packing methods
The indicated -xxx are the last three digits of the 12NC ordering code.[1]
Type number
Package
Description
Packing quantity
1000
-115
4000
PBSS8110X
SOT89
8 mm pitch, 12 mm tape and reel
-135
[1] For further information and the availability of packing methods, see Section 15.
PBSS8110X_2
© NXP B.V. 2009. All rights reserved.
Product data sheet
Rev. 02 — 11 December 2009
11 of 15
