Nexperia
PBSS5350T-Q
50 V, 3 A PNP low VCEsat transistor
8. Limiting values
Table 5. Limiting values
In accordance with the Absolute Maximum Rating System (IEC 60134).
Symbol
VCBO
VCEO
VEBO
IC
Parameter
Conditions
Min
Max
-50
-50
-5
Unit
V
collector-base voltage
open emitter
-
-
-
-
-
collector-emitter voltage open base
V
emitter-base voltage
collector current
open collector
V
-2
A
ICRM
repetitive peak collector δ ≤ 0.25; Operated under pulsed
-3
A
current
conditions; tp ≤ 100 ms
ICM
IB
peak collector current
base current
single pulse; tp ≤ 1 ms
-
-5
A
-
-0.5
300
480
540
500
1.2
A
Ptot
total power dissipation
Tamb ≤ 25 °C
[1]
-
mW
mW
mW
mW
W
[2]
-
[3]
-
[4]
-
[1] [5]
-
Tj
junction temperature
ambient temperature
storage temperature
-
150
150
150
°C
Tamb
Tstg
-65
-65
°C
°C
[1] Device mounted on an FR4 PCB, single-sided copper, tin-plated and standard footprint.
[2] Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for collector 1 cm2.
[3] Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for collector 6 cm2.
[4] Device mounted on an FR4 PCB, 4-layer copper, tin-plated and standard footprint.
[5] Operated under pulsed conditions: pulse width tp ≤ 100 ms; duty cycle δ ≤ 0.25.
9. Thermal characteristics
Table 6. Thermal characteristics
Symbol
Parameter
Conditions
Min
Typ
Max
Unit
K/W
K/W
K/W
K/W
K/W
K/W
Rth(j-a)
thermal resistance from in free air
junction to ambient
[1]
-
-
-
-
-
-
-
417
260
230
250
104
-
[2]
-
[3]
-
[4]
-
[1] [5]
-
Rth(j-sp)
thermal resistance from
junction to solder point
75
[1] Device mounted on an FR4 PCB, single-sided copper, tin-plated and standard footprint.
[2] Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for collector 1 cm2.
[3] Device mounted on an FR4 PCB, single-sided copper, tin-plated, mounting pad for collector 6 cm2.
[4] Device mounted on an FR4 PCB, 4-layer copper, tin-plated and standard footprint.
[5] Operated under pulsed conditions: pulse width tp ≤ 100 ms; duty cycle δ ≤ 0.25
©
PBSS5350T-Q
All information provided in this document is subject to legal disclaimers.
Nexperia B.V. 2022. All rights reserved
Product data sheet
10 May 2022
3 / 11
