µPD75216A
4. MEMORY CONFIGURATION
• Program memory (ROM) ................................. 16256 words × 8 bits
• 0000H to 0001H : Vector table for writing program start address by reset
• 0002H to 000FH : Vector table for writing program start address by interrupt
• 0020H to 007FH : Table area to be referred to by GETI instruction
• Data Memory
• Data area ....................................................... 512 words × 4 bits (000H to 1FFH)
• Peripheral hardware area ............................ 128 words × 4 bits (F80H to FFFH)
