10. TIMER/COUNTER FUNCTIONS (REAL-TIME PULSE UNIT)
{ Measures the pulse interval and frequency, and outputs a programmable pulse
•
•
16-bit measurements are possible
Can generate a variety of pulse patterns (interval pulse, one-shot pulse)
{ Timer 1
•
•
•
•
•
•
16-bit timer/event counter
Count clock sources: 2 types (division of internal system clock, and external pulse input)
Capture/compare common registers: 24
Count clear pins: TCLR10 to TCLR15
Interrupt sources: 30 types
External pulse outputs: 12
{ Timer 4
•
•
•
•
16-bit interval timer
Count clock can be selected from internal system clock divisions
Compare registers: 2
Interrupt sources: 2
