DDR3(L) 4Gb SDRAM
NT5CB(C)512M8DN / NT5CB(C)256M16DP
Temperature Range
Condition
Parameter
Value
Unit
C
C
C
C
C
C
C
C
C
C
Notes
Normal Operating Temperature Range
Extended Temperature Range
0 ≤ TOPER ≤ 85
85 < TOPER ≤ 95
-40 ≤ TOPER ≤ 85
85 < TOPER ≤ 95
-40 ≤ TOPER ≤ 85
85 < TOPER ≤ 95
-40 ≤ TOPER ≤ 85
85 < TOPER ≤ 105
-40 ≤ TOPER ≤ 85
85 < TOPER ≤ 95
1
1,2
1
Commercial
Normal Operating Temperature Range
Extended Temperature Range
Quasi Industrial
Industrial
1,2
1
Normal Operating Temperature Range
Extended Temperature Range
1,2
1
Normal Operating Temperature Range
Extended Temperature Range
Automotive Grade 2
Automotive Grade 3
1,2
1
Normal Operating Temperature Range
Extended Temperature Range
1,2
Note:
1. Operating Temperature TOPER is the case surface temperature on the center/top side of the DRAM.
2. Some applications require operation of the DRAM in the Extended Temperature Range between 85C and 95C case temperature.
Full specifications are guaranteed in this range, but the following additional apply.
a) Refresh commands must be doubled in frequency, therefore, reducing the Refresh interval tREFI to 3.9us.
b) If Self-Refresh operation is required in the Extended Temperature Range, then it is mandatory to either use the Manual
Self-Refresh mode with Extended Temperature Range capability (MR2 A6=0 and MR2 A7=1) or enable the optional Auto
Self-Refresh mode (MR2 A6=1 and MR2 A7=0).
