Ceramic Filters (CERAFILr) for FM Receivers
Discriminators Chip Low-profile Type CDSCA Series
4.5±0.1
CDSCA10M7 series forms a resonator on a piezo electric
ceramic sabstrate. In combination with ICs, this type
obtains stable demoduration characteristics in wide
0.2±0.2
0.4±0.05
bandwidth.
4.1max
■ Features
0.4(ref.)
0.4(ref.)
0.8±0.1
1. Compact and high reliability and recommended for
0.8
±
0.1
automotive applications.
2. Can be combined with various ICs. The IC is
determined by the last number in the part number.
3. Stable demoduration characteristics can be
obtained without adjustment.
1.5
±
0.1
1.5±0.1
(in mm)
4. Stable temperature characteristics.
5. Recommended for Pb free soldering.
Center Frequency (fo) Recovered Audio 3dB BW Recovered Audio Output Distortion
Part Number
IC
Detection Method
(MHz)
(kHz)
(mV)
(% )
CDSCA10M7GF107-R0
10.700 (fn)
fn±80 min.
52 min.
3.0 max. TA31272F
Quadrature
(fn) means nominal center frequency.
■ Standard Land Pattern Dimensions
3.0
1.0
2.0
1.0
(in mm)
12
42
