Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
P61E7.pdf 01.10.17
Ceramic Filters (CERAFILr) for FM Receivers
Discriminators CDALA Series
8.0±1.0
Freq. Rank (Color Dot)
CDALA10M7 series forms a resonator on a piezoelectric
ceramic substrate. In combination with ICs, this type
obtains stable demodulation characteristics in wide
E
C
I
A
J
M
A
R
K
I
N
G
O
D
E
bandwidths.
0.4±0.1
0.5±0.1
0.65±0.1
5.0±0.2
■ Features
1. Compact and excellent mechanical strength.
2. Can be combined with various ICs. The IC is
determined by the last number in the part number.
3. Stable demodulation characteristics can be obtained
without adjustment.
CDALA10M7G_ Series
(in mm)
4. The MG type for wide bandwidths and the MC type for
narrow bandwidths are available.
8.0±1.0
Freq. Rank (Color Dot)
5. Stable temperature characteristics.
6. We recommend combination : ceramic discriminator
CDALA10M7 series and "CERAFIL" SFELA10M7 of the
same frequency rank.
E
C
I
A
J
M
A
R
K
I
N
G
O
D
E
0.4±0.1
0.5±0.1
0.65±0.1
5.0±0.2
CDALA10M7C_ Series
(in mm)
Center Frequency (fo) Recovered Audio 3dB BW Recovered Audio Output Distortion
Part Number
IC
Detection Method
(MHz)
(kHz)
(mV)
(% )
CDALA10M7GA001-B0
CDALA10M7GA016-B0
CDALA10M7GA018-B0
CDALA10M7GA046-B0
CDALA10M7GA048-B0
CDALA10M7GA092-B0
CDALA10M7CA001-B0
CDALA10M7CA005A-B0
CDALA10M7CA040-B0
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
345 min.
300 min.
300 min.
330 min.
400 min.
300 min.
242 min.
100 min.
130 min.
25 min.
within60 to 90mV
60 min.
0.6 max. CX20029
0.9 max. TA8122F
0.9 max. TA8132N
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
280 min.
1.0 max.
1.0 max.
LA1832
LA1835
700 min.
60 min.
1.0 max. TA2132P
35 min.
-
CX20091
LA7770
600 min.
6.0 max.
40 min.
0.7 max. TEA5710
■ Center Frequency Rank Code
CODE
30kHz Step
25kHz Step
13
D
B
A
C
E
Z
10.64MHz±30kHz
10.67MHz±30kHz
10.70MHz±30kHz
10.73MHz±30kHz
10.76MHz±30kHz
10.650MHz±25kHz
10.675MHz±25kHz
10.700MHz±25kHz
10.725MHz±25kHz
10.750MHz±25kHz
Combination A,B,C,D,E
Combination A,B,C
M
45
