Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
P61E7.pdf 01.10.17
Ceramic Filters (CERAFILr) for FM Receivers
Discriminators Chip Type CDACV Series
3.4±0.5
1.5±0.3
CDACV10M7 series forms a resonator on a piezoelectric
ceramic substrate. In combination with ICs, this type
obtains stable demodulation characteristics in wide
bandwidths.
■ Features
0.9±0.3
0.9±0.3
1. Compact and excellent mechanical strength.
2. Can be combined with various ICs. The IC is
determined by the last number in the part number.
3. Stable demodulation characteristics can be obtained
without adjustment.
: EIAJ Monthly Code
: Rank
in mm
4. The MG type for wide bandwidths and the MC type for
narrow bandwidths are available.
5. Stable temperature characteristics.
6. We recommend kits : ceramic discriminator
CDACV10M7 series and "CERAFIL" SFECV10M7 of the
same frequency rank.
Center Frequency (fo) Recovered Audio 3dB BW Recovered Audio Output Distortion
Part Number
IC
Detection Method
(MHz)
(kHz)
(mV)
(% )
CDACV10M7GA001-R0
CDACV10M7GA016-R0
CDACV10M7GA046-R0
CDACV10M7GA069-R0
CDACV10M7CA001-R0
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
10.700 ±30kHz
fo±150 min.
300 min.
55 min.
within60 to 90mV
280 min.
1.0 max. CX20029
0.9 max. TA8122F
Quadrature
Quadrature
Quadrature
Quadrature
Quadrature
330 min.
1.5 max.
LA1832
330 min.
80 min.
1.0 max. CXA1538N
1.0 max. CX20091
fo±150 min.
55 min.
■ Center Frequency Rank Code
CODE
30kHz Step
25kHz Step
D
B
A
C
E
Z
10.64MHz±30kHz
10.67MHz±30kHz
10.70MHz±30kHz
10.73MHz±30kHz
10.76MHz±30kHz
10.650MHz±25kHz
10.675MHz±25kHz
10.700MHz±25kHz
10.725MHz±25kHz
10.750MHz±25kHz
11
Combination A,B,C,D,E
Combination A,B,C
M
■ Standard Land Pattern Dimensions
1.5
1.5
1.4
1.5
1.4
38
