High Dielectric Constant Type X7R(R7) Characteristics
LxW [mm]
0.4x0.2(02)<01005>
10(1A)
Rated Volt. [Vdc]
Capacitance
68pF(680)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
Part Number
GRM022R71A680KA01L
GRM022R71A101KA01L
GRM022R71A151KA01L
GRM022R71A221KA01L
GRM022R71A331KA01L
GRM022R71A471KA01L
100pF(101)
150pF(151)
220pF(221)
330pF(331)
470pF(471)
LxW [mm]
0.6x0.3(03)<0201>
16(1C)
Rated Volt. [Vdc]
Capacitance
100pF(101)
150pF(151)
220pF(221)
330pF(331)
470pF(471)
680pF(681)
1000pF(102)
1500pF(152)
2200pF(222)
3300pF(332)
4700pF(472)
6800pF(682)
10000pF(103)
25(1E)
10(1A)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
Part Number
GRM033R71E101KA01D
GRM033R71E151KA01D
GRM033R71E221KA01D
GRM033R71E331KA01D
GRM033R71E471KA01D
GRM033R71E681KA01D
GRM033R71E102KA01D
GRM033R71E152KA01D
GRM033R71C222KA88D
GRM033R71C332KA88D
GRM033R71A472KA01D
GRM033R71A682KA01D
GRM033R71A103KA01D
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
qProduct ID
tTemperature Characteristics
iCapacitance Tolerance
wSeries
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging*
rDimension (T)
uCapacitance
(Part Number) GR
M
02
2
R7 1A 680
K
A01
L
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD 180mm Reel Taping.
*GRM022: D is applicable.
