Temperature Compensating Type P2H(6P) Characteristics
LxW [mm]
1.0x0.5(15)<0402>
50(1H)
Rated Volt. [Vdc]
Capacitance
Tolerance
1.0pF(1R0) ±0.25pF(C)
2.0pF(2R0) ±0.25pF(C)
3.0pF(3R0) ±0.25pF(C)
4.0pF(4R0) ±0.25pF(C)
5.0pF(5R0) ±0.25pF(C)
GRM1556P1H1R0CZ01D
GRM1556P1H2R0CZ01D
GRM1556P1H3R0CZ01D
GRM1556P1H4R0CZ01D
GRM1556P1H5R0CZ01D
GRM1556P1H6R0DZ01D
GRM1556P1H7R0DZ01D
GRM1556P1H8R0DZ01D
GRM1556P1H9R0DZ01D
GRM1556P1H100JZ01D
GRM1556P1H120JZ01D
GRM1556P1H150JZ01D
GRM1556P1H180JZ01D
GRM1556P1H220JZ01D
GRM1556P1H270JZ01D
6.0pF(6R0)
7.0pF(7R0)
8.0pF(8R0)
9.0pF(9R0)
10pF(100)
12pF(120)
15pF(150)
18pF(180)
22pF(220)
27pF(270)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
Temperature Compensating Type R2H(6R) Characteristics
LxW [mm]
0.6x0.3(03)<0201>
25(1E)
1.0x0.5(15)<0402>
50(1H)
Rated Volt. [Vdc]
Capacitance
Tolerance
Part Number
1.0pF(1R0) ±0.25pF(C)
2.0pF(2R0) ±0.25pF(C)
3.0pF(3R0) ±0.25pF(C)
4.0pF(4R0) ±0.25pF(C)
5.0pF(5R0) ±0.25pF(C)
GRM0336R1E1R0CD01D
GRM0336R1E2R0CD01D
GRM0336R1E3R0CD01D
GRM0336R1E4R0CD01D
GRM0336R1E5R0CD01D
GRM0336R1E6R0DD01D
GRM0336R1E7R0DD01D
GRM0336R1E8R0DD01D
GRM0336R1E9R0DD01D
GRM0336R1E100JD01D
GRM0336R1E120JD01D
GRM0336R1E150JD01D
GRM0336R1E180JD01D
GRM0336R1E220JD01D
GRM0336R1E270JD01D
GRM0336R1E330JD01D
GRM0336R1E390JD01D
GRM0336R1E470JD01D
GRM0336R1E560JD01D
GRM0336R1E680JD01D
GRM0336R1E820JD01D
GRM0336R1E101JD01D
GRM1556R1H1R0CD01D
GRM1556R1H2R0CZ01D
GRM1556R1H3R0CZ01D
GRM1556R1H4R0CZ01D
GRM1556R1H5R0CZ01D
GRM1556R1H6R0DZ01D
GRM1556R1H7R0DZ01D
GRM1556R1H8R0DZ01D
GRM1556R1H9R0DZ01D
GRM1556R1H100JZ01D
GRM1556R1H120JZ01D
GRM1556R1H150JZ01D
GRM1556R1H180JZ01D
GRM1556R1H220JZ01D
GRM1556R1H270JZ01D
GRM1556R1H330JZ01D
6.0pF(6R0)
7.0pF(7R0)
8.0pF(8R0)
9.0pF(9R0)
10pF(100)
12pF(120)
15pF(150)
18pF(180)
22pF(220)
27pF(270)
33pF(330)
39pF(390)
47pF(470)
56pF(560)
68pF(680)
82pF(820)
100pF(101)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
