Temperature Compensating Type S2H(6S) Characteristics
LxW [mm]
0.6x0.3(03)<0201>
25(1E)
1.0x0.5(15)<0402>
50(1H)
Rated Volt. [Vdc]
Capacitance
Tolerance
Part Number
1.0pF(1R0) ±0.25pF(C)
2.0pF(2R0) ±0.25pF(C)
3.0pF(3R0) ±0.25pF(C)
4.0pF(4R0) ±0.25pF(C)
5.0pF(5R0) ±0.25pF(C)
GRM0336S1E1R0CD01D
GRM0336S1E2R0CD01D
GRM0336S1E3R0CD01D
GRM0336S1E4R0CD01D
GRM0336S1E5R0CD01D
GRM0336S1E6R0DD01D
GRM0336S1E7R0DD01D
GRM0336S1E8R0DD01D
GRM0336S1E9R0DD01D
GRM0336S1E100JD01D
GRM0336S1E120JD01D
GRM0336S1E150JD01D
GRM0336S1E180JD01D
GRM0336S1E220JD01D
GRM0336S1E270JD01D
GRM0336S1E330JD01D
GRM0336S1E390JD01D
GRM0336S1E470JD01D
GRM0336S1E560JD01D
GRM0336S1E680JD01D
GRM0336S1E820JD01D
GRM0336S1E101JD01D
GRM1556S1H1R0CD01D
GRM1556S1H2R0CZ01D
GRM1556S1H3R0CZ01D
GRM1556S1H4R0CZ01D
GRM1556S1H5R0CZ01D
GRM1556S1H6R0DZ01D
GRM1556S1H7R0DZ01D
GRM1556S1H8R0DZ01D
GRM1556S1H9R0DZ01D
GRM1556S1H100JZ01D
GRM1556S1H120JZ01D
GRM1556S1H150JZ01D
GRM1556S1H180JZ01D
GRM1556S1H220JZ01D
GRM1556S1H270JZ01D
GRM1556S1H330JZ01D
GRM1556S1H390JZ01D
6.0pF(6R0)
7.0pF(7R0)
8.0pF(8R0)
9.0pF(9R0)
10pF(100)
12pF(120)
15pF(150)
18pF(180)
22pF(220)
27pF(270)
33pF(330)
39pF(390)
47pF(470)
56pF(560)
68pF(680)
82pF(820)
100pF(101)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
qProduct ID
tTemperature Characteristics
iCapacitance Tolerance
wSeries
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging
rDimension (T)
uCapacitance
(Part Number) GR
M
03
3
6S 1E 1R0
C
D01
D
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD 180mm Reel Taping.
