High Dielectric Constant Type X7R(R7)/X7U(E7) Characteristics
LxW [mm]
3.2x1.6(31)<1206>
Rated Volt. [Vdc]
Capacitance
15000pF(153)
22000pF(223)
33000pF(333)
47000pF(473)
68000pF(683)
0.10µF(104)
0.15µF(154)
0.22µF(224)
0.33µF(334)
0.47µF(474)
0.68µF(684)
1.0µF(105)
100(2A)
50(1H)
25(1E)
16(1C)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
Part Number
GRM319R72A153KA01L
GRM31MR72A223KA01L
GRM31MR72A333KA01L
GRM31MR72A473KA01L
GRM31MR72A683KA01L
GRM319R72A104KA01D
GRM31MR72A154KA01L
GRM31MR72A224KA01L
GRM31MR71H154KA01L
GRM31MR71H224KA01L
GRM319R71H334KA01D
GRM31MR71H474KA01L
GRM31MR71H684KA88L
GRM31MR71H105KA88L
GRM31CR71H225KA88L
GRM31CR71H475KA12L
GRM31MR72A474KA35L
GRM31MR72A684KA35L
GRM31CR72A105KA01L
2.2µF(225)
GRM31MR71E225KA93L
GRM31CR71E475KA88L
GRM31MR71C225KA35L
GRM31CR71C475KA01L
4.7µF(475)
10µF(106)
GRM31CR71E106KA12L* GRM31CR71C106KAC7L*
LxW [mm]
3.2x1.6(31)<1206>
6.3(0J)
Rated Volt. [Vdc]
Capacitance
10µF(106)
10(1A)
4(0G)
Tolerance
±10% (K)
±20% (M)
±20% (M)
Part Number
GRM31CR71A106KA01L
22µF(226)
GRM31CR71A226ME15L* GRM31CR70J226ME19L*
47µF(476)
GRM31CE70G476ME15L*
LxW [mm]
3.2x2.5(32)<1210>
Rated Volt. [Vdc]
Capacitance
0.68µF(684)
1.0µF(105)
2.2µF(225)
4.7µF(475)
10µF(106)
100(2A)
50(1H)
35(YA)
25(1E)
Tolerance
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±10% (K)
±20% (M)
Part Number
GRM32CR72A684KA01L
GRM32CR72A105KA35L
GRM32ER72A225KA35L
GRM32NR71H684KA01L
GRM32ER71H475KA88L
GRM32ER7YA106KA12L
GRM32DR71E106KA12L
GRM32ER71E226ME15L*
22µF(226)
LxW [mm]
3.2x2.5(32)<1210>
10(1A)
Rated Volt. [Vdc]
Capacitance
22µF(226)
16(1C)
6.3(0J)
Tolerance
±20% (M)
±20% (M)
Part Number
GRM32ER71C226ME18L*
47µF(476)
GRM32ER71A476ME15L* GRM32ER70J476ME20L*
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
*: Please refer to GRM Series Specifications and Test Method(2).
qProduct ID
wSeries
tTemperature Characteristics
iCapacitance Tolerance
eDimension (LxW)
yRated Voltage
oIndividual Specification Code !Packaging
rDimension (T)
uCapacitance
(Part Number) GR
M
31
9
R7 2A 153
K
A01
L
q
w
e
r
t
y
u
i
o
!
Packaging Code in Part Number is a code shows STD 180mm Reel Taping.
