Temperature Compensating Type T2H(6T) Characteristics
LxW [mm]
0.6x0.3(03)<0201>
25(1E)
1.0x0.5(15)<0402>
50(1H)
Rated Volt. [Vdc]
Capacitance
Tolerance
Part Number
1.0pF(1R0) ±0.25pF(C)
2.0pF(2R0) ±0.25pF(C)
3.0pF(3R0) ±0.25pF(C)
4.0pF(4R0) ±0.25pF(C)
5.0pF(5R0) ±0.25pF(C)
GRM0336T1E1R0CD01D
GRM0336T1E2R0CD01D
GRM0336T1E3R0CD01D
GRM0336T1E4R0CD01D
GRM0336T1E5R0CD01D
GRM0336T1E6R0DD01D
GRM0336T1E7R0DD01D
GRM0336T1E8R0DD01D
GRM0336T1E9R0DD01D
GRM0336T1E100JD01D
GRM0336T1E120JD01D
GRM0336T1E150JD01D
GRM0336T1E180JD01D
GRM0336T1E220JD01D
GRM0336T1E270JD01D
GRM0336T1E330JD01D
GRM0336T1E390JD01D
GRM0336T1E470JD01D
GRM0336T1E560JD01D
GRM0336T1E680JD01D
GRM0336T1E820JD01D
GRM0336T1E101JD01D
GRM1556T1H1R0CD01D
GRM1556T1H2R0CD01D
GRM1556T1H3R0CD01D
GRM1556T1H4R0CD01D
GRM1556T1H5R0CD01D
GRM1556T1H6R0DD01D
GRM1556T1H7R0DD01D
GRM1556T1H8R0DD01D
GRM1556T1H9R0DD01D
GRM1556T1H100JD01D
GRM1556T1H120JD01D
GRM1556T1H150JD01D
GRM1556T1H180JD01D
GRM1556T1H220JD01D
GRM1556T1H270JD01D
GRM1556T1H330JD01D
GRM1556T1H390JD01D
GRM1556T1H470JD01D
GRM1556T1H560JD01D
GRM1556T1H680JD01D
GRM1556T1H820JD01D
GRM1556T1H101JD01D
6.0pF(6R0)
7.0pF(7R0)
8.0pF(8R0)
9.0pF(9R0)
10pF(100)
12pF(120)
15pF(150)
18pF(180)
22pF(220)
27pF(270)
33pF(330)
39pF(390)
47pF(470)
56pF(560)
68pF(680)
82pF(820)
100pF(101)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±0.5pF(D)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
±5% (J)
The part number code is shown in ( ) and Unit is shown in [ ].
< >: EIA [inch] Code
