DLY — Enable Oscillator Start-Up Delay on Exit from STOP
0 = No stabilization delay on exit from STOP
1 = Stabilization delay enabled on exit from STOP
CME — Clock Monitor Enable
0 = Clock monitor disabled; slow clocks can be used
1 = Slow or stopped clocks cause clock failure reset
CR1, CR0 — COP Timer Rate Select
Divide
XTAL = 4.0 Mhz
Timeout
XTAL = 8.0 MHz
Timeout
XTAL = 12.0 MHz
Timeout
15
CR [1:0]
E/2
–0/+32.8 ms
–0/+16.4 ms
–0/+10.9 ms
By
0 0
0 1
1 0
1 1
1
32.768 ms
131.072 ms
524.288 ms
2.097 sec
1.0 MHz
16.384 ms
65.536 ms
262.140 ms
1.049 sec
2.0 MHz
10.923 ms
43.691 ms
174.76 ms
699.05 ms
3.0 MHz
4
16
64
E =
COPRST — Arm/Reset COP Timer Circuitry
$103A
Bit 7
6
6
0
5
5
0
4
4
0
3
3
0
2
2
0
1
1
0
Bit 0
7
0
0
0
RESET:
Write $55 to COPRST to arm COP watchdog clearing mechanism. Write $AA to COPRST to reset COP
watchdog.
HPRIO — Highest Priority I-Bit Interrupt and Miscellaneous
$103C
Bit 7
6
5
4
3
PSEL3
0
2
PSEL2
1
1
PSEL1
0
Bit 0
PSEL0
1
RBOOT SMOD
MDA
—
IRV
—
RESET:
—
—
RBOOT — Read Bootstrap ROM Bits 7–4
Refer to 2 Operating Modes and Memory Maps.
SMOD — Special Mode Select
Refer to 2 Operating Modes and Memory Maps.
MDA — Mode Select A
Refer to 2 Operating Modes and Memory Maps.
IRV — Internal Read Visibility
Refer to 2 Operating Modes and Memory Maps.
PSEL[3:0] — Priority Select Bits 3 through 0
Can be written only while the I bit in the CCR is set (interrupts disabled). These bits select one interrupt
source to be elevated above all other I-bit related sources.
MC68HC11A8
MC68HC11A8TS/D
MOTOROLA
15
