Mitsubishi microcomputers
M16C / 61 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Timer B
When measuring measurement pulse time interval from falling edge to falling edge
Count source
“H”
“L”
Measurement pulse
Transfer
Transfer
(indeterminate value)
(measured value)
Reload register counter
transfer timing
(Note 1)
(Note 1)
(Note 2)
Timing at which counter
reaches “000016
”
“1”
“0”
Count start flag
“1”
“0”
Timer Bi interrupt
request bit
Cleared to “0” when interrupt request is accepted, or cleared by software.
“1”
“0”
Timer Bi overflow flag
Note 1: Counter is initialized at completion of measurement.
Note 2: Timer has overflowed.
Figure 1.16.19. Operation timing when measuring a pulse period
Count source
“H”
Measurement pulse
“L”
Transfer
(measured value)
Transfer
(measured value)
Transfer
(indeterminate
value)
Transfer
(measured
value)
Reload register counter
transfer timing
(Note 1)
(Note 1)
(Note 1) (Note 1)
(Note 2)
Timing at which counter
reaches “000016
”
“1”
“0”
Count start flag
“1”
“0”
Timer Bi interrupt
request bit
Cleared to “0” when interrupt request is accepted, or cleared by software.
“1”
“0”
Timer Bi overflow flag
Note 1: Counter is initialized at completion of measurement.
Note 2: Timer has overflowed.
Figure 1.16.20. Operation timing when measuring a pulse width
86
