Mitsubishi microcomputers
M16C / 61 Group
SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER
Timer A
One-shot start flag
Symbol
ONSF
Address
038216
When reset
b7 b6 b5 b4 b3 b2 b1 b0
00X00000
2
R W
Bit symbol
Bit name
Function
Timer A0 one-shot start flag
Timer A1 one-shot start flag
Timer A2 one-shot start flag
Timer A3 one-shot start flag
Timer A4 one-shot start flag
TA0OS
TA1OS
TA2OS
TA3OS
TA4OS
1 : Timer start
When read, the value is “0”
Nothing is assigned.
In an attempt to write to this bit, write “0”. The value, if read, turns out to be indeterminate.
b7 b6
TA0TGL
Timer A0 event/trigger
select bit
0 0 : Input on TA0IN is selected (Note)
0 1 : TB2 overflow is selected
1 0 : TA4 overflow is selected
1 1 : TA1 overflow is selected
TA0TGH
Note: Set the corresponding port direction register to “0”.
Trigger select register
Symbol
TRGSR
Address
038316
When reset
0016
b7 b6 b5 b4 b3 b2 b1 b0
Bit symbol
TA1TGL
Bit name
Function
R W
b1 b0
Timer A1 event/trigger
select bit
0 0 : Input on TA1IN is selected (Note)
0 1 : TB2 overflow is selected
1 0 : TA0 overflow is selected
1 1 : TA2 overflow is selected
TA1TGH
TA2TGL
b3 b2
Timer A2 event/trigger
select bit
0 0 : Input on TA2IN is selected (Note)
0 1 : TB2 overflow is selected
1 0 : TA1 overflow is selected
1 1 : TA3 overflow is selected
TA2TGH
TA3TGL
TA3TGH
b5 b4
Timer A3 event/trigger
select bit
0 0 : Input on TA3IN is selected (Note)
0 1 : TB2 overflow is selected
1 0 : TA2 overflow is selected
1 1 : TA4 overflow is selected
b7 b6
Timer A4 event/trigger
select bit
TA4TGL
TA4TGH
0 0 : Input on TA4IN is selected (Note)
0 1 : TB2 overflow is selected
1 0 : TA3 overflow is selected
1 1 : TA0 overflow is selected
Note: Set the corresponding port direction register to “0”.
Clock prescaler reset flag
b7 b6 b5 b4 b3 b2 b1 b0
Symbol
CPSRF
Address
038116
When reset
0XXXXXXX
2
Bit symbol
Bit name
Function
R W
Nothing is assigned.
In an attempt to write to these bits, write “0”. The value, if read, turns out to be
indeterminate.
0 : No effect
1 : Prescaler is reset
CPSR
Clock prescaler reset flag
(When read, the value is “0”)
Figure 1.16.5. Timer A-related registers (3)
73
