MT9079
.
Bit
Name
Functional Description
Bit
Name
Functional Description
3
TBUF0
TBUF1
RBUF0
RBUF1
Transmit Buffer Zero Connect. If one,
the contents of the transmit circular
buffer zero will be transmitted in the
corresponding time slot beginning at
the next multiframe boundary. If zero,
circular buffer zero is not connected
to this time slot. This buffer is acces-
sible only in processor and controller
modes.
7 - 0 TxB0.n .7 - Transmit Bits 7 to 0. This byte is
transmitted on a time slot selected by
TxB0.n .0
the TBUF0 bit of the appropriate per
time slot control word. n = 0 to 15 and
represents a byte position in Trans-
mit Circular Buffer zero (TxB0).
Table 19 - Transmit Circular Buffer Zero (Page 9)
Page 0AH, addresses 10000 to 11111 contain the 16
bytes of transmit circular buffer one (TxB1.0 to
TxB1.15 respectively). This feature is functional only
in processor and controller modes.
2
1
0
Transmit Buffer One Connect. If one,
the contents of the transmit circular
buffer one will be transmitted in the
corresponding time slot beginning at
the next multiframe boundary. If zero,
circular buffer one is not connected
to this time slot. This buffer is acces-
sible only in processor and controller
modes.
Bit
Name
Functional Description
7 - 0 TxB1.n .7 - Transmit Bits 7 to 0. This byte is
transmitted on a time slot selected by
the TBUF1 bit of the appropriate per
time slot control word. n = 0 to 15 and
represents a byte position in Trans-
mit Circular Buffer zero (TxB1).
TxB1.n .0
Receive Buffer Zero Connect. If one,
the data of the corresponding receive
time slot will be recorded in receive
circular buffer zero beginning at the
next multiframe boundary. If zero, cir-
cular buffer zero is not connected to
this time slot. This buffer is accessi-
ble only in processor and controller
modes.
Table 20 - Transmit Circular Buffer One (Page A)
Receive Circular Buffers One and Zero (Pages B
and C)
Receive Buffer One Connect. If one,
the data of the corresponding receive
time slot will be recorded in receive
circular buffer one beginning at the
next multiframe boundary. If zero, cir-
cular buffer one will not connected to
this time slot. This buffer is accessi-
ble only in processor and controller
modes.
Page 0BH, addresses 10000 to 11111 contain the 16
bytes of receive circular buffer zero (RxB0.0 to
RxB0.15 respectively). This feature is functional only
in processor and controller modes.
Bit
Name
Functional Description
7 - 0
RxB0.n .7 Receive Bits 7 to 0. This byte is
Table 18 - Per Time Slot Control Words
(Pages 7 and 8) (continued)
-
received from a time slot selected by
the RBUF0 bit of the appropriate per
time slot control words. n = 0 to 15
and represents a byte position in
receive circular buffer zero (RxB0).
RxB0.n .0
Transmit Circular Buffers One and Zero (Pages 9
and A)
Table 21 - Receive Circular Buffer Zero (Page B)
Page 09H, addresses 10000 to 11111 contain the 16
bytes of transmit circular buffer zero (TxB0.0 to
TxB0.15 respectively). This feature is functional only
in processor and controller modes.
Page 0CH, addresses 10000 to 11111 contain the 16
bytes of receive circular buffer one (RxB1.0 to
RxB1.15 respectively). This feature is functional only
in processor and controller modes.
The transmit circular buffers are not cleared by the
RST function, nor are they cleared by the RESET
function.
Bit
Name
Functional Description
7 - 0
RxB1.n .7 Receive Bits 7 to 0. This byte is
-
received from a time slot selected by
the RBUF1 bit of the appropriate per
time slot control words. n = 0 to 15
and represents a byte position in
receive circular buffer one (RxB1).
RxB1.n .0
Table 22 - Receive Circular Buffer One (Page C)
4-260
