Master Control 2 (Page-2)
20.4.1 Master Control 2 (Page 02H) (E1)
Register
Names
Address
(A4A3A2A1A0)
10H (Table 105) Configuration Control Word
11H (Table 106) LIU Tx Word
T1/E1, TxEN, LIUEn, ELOS, Tx8KEN, ADSEQ
WR, Pk2, Pk1, CPL, TxLB2-0
12H
Reserved
Set all bits to zero for normal operation.
13H (Table 107) Jitter Attenuator Control Word
JFC, JFD2-JFD0, JACL
14H
15H
Reserved
Reserved
Set all bits to zero for normal operation.
Set all bits to zero for normal operation.
16H (Table 108) Equalizer High Threshold
17H (Table 109) Equalizer Low Threshold
18H (Table 110) Serial Bit Rate
EHT7-0
ELT7-0
IMA,8Men,8MTS1-0
En, SaSEL, CH4-0
En, CH4-0
En, CH4-0
CP6-0
19H (Table 111) HDCL0 Select
1AH (Table 112) HDCL1 Select
1BH (Table 113) HDLC2 Select
1CH(Table 114) Custom Pulse Word 1
1DH(Table 115) Custom Pulse Word 2
1EH (Table 116) Custom Pulse Word 3
1FH (Table 117) Custom Pulse Word 4
CP6-0
CP6-0
CP6-0
Table 103 - Master Control 2 (Page 02H) (E1)
