SDA 9380 - B21
Preliminary Data Sheet
Recommended operating conditions
8 Recommended operating conditions
Parameter
Symbol Min
Nom Max
Unit Remark
1
Supply voltages
VDD(D)
3.0
3.3
3.45
V
)
VDD(A1..4)
1
Supply voltage
V
7.2
0
8.0
25
8.4
70
V
)
DD(MC)
Ambient temperature
TA
°C
1) Any sequence and any rise time of the 3.3V and 8V supply voltage is allowed at power on. But all VSS
pins as well as SUBST pin have to be connected to ground when applying any voltage.
TTL Inputs: VSYNC, RESN, TEST, FH1_2, CLEXT, SSD
High-level input voltage
Low-level input voltage
VIH
VIL
2.0V
0
VDD
0.8
V
V
TTL Inputs: CLKI (CLEXT=High)
High-level input voltage
Low-level input voltage
Input VPROT
VIH
VIL
2.0V
0
5.5
0.8
V
V
Threshold V1
1.4
0.9
1.5
1.0
1.6
1.1
V
V
Threshold V2
Input HPROT
Threshold V1
2.65
1.4
2.7
1.5
2.75
1.6
V
V
Threshold V2
Input BSOIN
Upper threshold (negative-going)
Upper threshold (positive-going)
Lower threshold
VTHn
VTHp
2.625
2.725
2.675*) 2.725
2.775*) 2.825
V
V
V
see 11.2
0.5
0.7
*) The comparator has a hysteresis of typ. 100mV.
Input HSAFE
Low input voltage
Full range input voltage
1.8
2.7
V
V
V
Input voltage at 31.25 kHz
Input voltage at 38 kHz
V31.25k
V38k
1.9
2.0
2.1
1.225
1.24
1.26
V31.25k related to V31.25k!
Micronas
8-43
2001-01-29
