Pre lim in a ry
MT9V012 - 1/6-In ch VGA CMOS Dig it a l Im a g e Se n so r
Re g ist e rs
Ta b le 6: Re g ist e r De scrip t io n (co n t in u e d )
Syn c’d
De fa u lt t o Fra m e
Ba d
Fra m e
Bit
Bit De scrip t io n
(h e x)
St a rt
0x64 (100) Gre e n 2 Ca lib ra t io n Va lu e
8:0
0
N
Y
Green2
Calibration
Value
Analog calibration offset for green2 pixels, represented as a
two’s complement signed 8-bit value (if [8] is clear, the offset
is positive and the magnitude is given by [7:0]. If [8] is set,
the offset is negative and the magnitude is given by Not
([7:0]) + 1). If Reg0x60[0] = 0, this register is read-only and
returns the current value computed by the black level
calibration algorithm. If Reg0x60[0] = 1, this register is read/
write and can be used to set the calibration offset manually.
Green2 pixels share rows with blue pixels.
0xC8 (200) Co n t e xt Co n t ro l
0
1
2
3
1
1
0
1
Y
Y
Y
Y
YM
YM
N
Horizontal
Blanking Select 0 = Use horizontal blanking context A, Reg0x07.
Vertical 1 = Use vertical blanking context B, Reg0x06.
Blanking Select 0 = Use vertical blanking context A, Reg0x08.
1 = Use horizontal blanking context B, Reg0x05.
LED Flash
Enable
Enable LED flash. Same physical register as Reg0x23[8].
YM
Read Mode
Select
1 = Use read mode context B, Reg0x20.
0 = Use read mode context A, Reg0x21.
Note that bits only found in read mode, context B register,
will always be taken from that register.
7
0
0
Y
N
N
Xenon Flash
Enable
Enable Xenon flash. Same physical register as Reg0x23[13].
15
YM
Restart
Setting this bit will cause the sensor to abandon the current
frame and start resetting the first row. Same physical
register as Reg0x0D[1].
