PIC24FJ64GA104 FAMILY
REGISTER 10-7: RPINR9: PERIPHERAL PIN SELECT INPUT REGISTER 9
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
U-0
—
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-1
IC5R4
R/W-1
IC5R3
R/W-1
IC5R2
R/W-1
IC5R1
R/W-1
IC5R0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-5
bit 4-0
Unimplemented: Read as ‘0’
IC5R<4:0>: Assign Input Capture 5 (IC5) to Corresponding RPn or RPIn Pin bits
REGISTER 10-8: RPINR11: PERIPHERAL PIN SELECT INPUT REGISTER 11
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
OCFBR4
OCFBR3
OCFBR2
OCFBR1
OCFBR0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
OCFAR4
OCFAR3
OCFAR2
OCFAR1
OCFAR0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
bit 7-5
Unimplemented: Read as ‘0’
OCFBR<4:0>: Assign Output Compare Fault B (OCFB) to Corresponding RPn or RPIn Pin bits
Unimplemented: Read as ‘0’
bit 4-0
OCFAR<4:0>: Assign Output Compare Fault A (OCFA) to Corresponding RPn or RPIn Pin bits
