PIC24FJ64GA104 FAMILY
REGISTER 10-3: RPINR3: PERIPHERAL PIN SELECT INPUT REGISTER 3
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
T3CKR4
T3CKR3
T3CKR2
T3CKR1
T3CKR0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
T2CKR4
T2CKR3
T2CKR2
T2CKR1
T2CKR0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
bit 7-5
Unimplemented: Read as ‘0’
T3CKR<4:0>: Assign Timer3 External Clock (T3CK) to Corresponding RPn or RPIn Pin bits
Unimplemented: Read as ‘0’
bit 4-0
T2CKR<4:0>: Assign Timer2 External Clock (T2CK) to Corresponding RPn or RPIn Pin bits
REGISTER 10-4: RPINR4: PERIPHERAL PIN SELECT INPUT REGISTER 4
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
T5CKR0
bit 8
T5CKR4
T5CKR3
T5CKR2
T5CKR1
bit 15
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
T4CKR4
T4CKR3
T4CKR2
T4CKR1
T4CKR0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
bit 7-5
Unimplemented: Read as ‘0’
T5CKR<4:0>: Assign Timer5 External Clock (T5CK) to Corresponding RPn or RPIn Pin bits
Unimplemented: Read as ‘0’
bit 4-0
T4CKR<4:0>: Assign Timer4 External Clock (T4CK) to Corresponding RPn or RPIn Pin bits
