PIC24FJ64GA104 FAMILY
REGISTER 10-9: RPINR18: PERIPHERAL PIN SELECT INPUT REGISTER 18
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
U1CTSR4
U1CTSR3
U1CTSR2
U1CTSR1
U1CTSR0
bit 15
bit 8
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
U1RXR4
U1RXR3
U1RXR2
U1RXR1
U1RXR0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
bit 7-5
Unimplemented: Read as ‘0’
U1CTSR<4:0>: Assign UART1 Clear to Send (U1CTS) to Corresponding RPn or RPIn Pin bits
Unimplemented: Read as ‘0’
bit 4-0
U1RXR<4:0>: Assign UART1 Receive (U1RX) to Corresponding RPn or RPIn Pin bits
REGISTER 10-10: RPINR19: PERIPHERAL PIN SELECT INPUT REGISTER 19
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
U2CTSR0
bit 8
U2CTSR4
U2CTSR3
U2CTSR2
U2CTSR1
bit 15
U-0
—
U-0
—
U-0
—
R/W-1
R/W-1
R/W-1
R/W-1
R/W-1
U2RXR4
U2RXR3
U2RXR2
U2RXR1
U2RXR0
bit 7
bit 0
Legend:
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 15-13
bit 12-8
bit 7-5
Unimplemented: Read as ‘0’
U2CTSR<4:0>: Assign UART2 Clear to Send (U2CTS) to Corresponding RPn or RPIn Pin bits
Unimplemented: Read as ‘0’
bit 4-0
U2RXR<4:0>: Assign UART2 Receive (U2RX) to Corresponding RPn or RPIn Pin bits
2010 Microchip Technology Inc.
DS39951C-page 133
