PIC18F2480/2580/4480/4580
Table 24-3 shows the relation between the clock
generated by the PLL and the frequency error from
jitter (measured jitter-induced error of 2%, Gaussian
distribution, within 3 standard deviations), as a
percentage of the nominal clock frequency.
This is clearly smaller than the expected drift of a
crystal oscillator, typically specified at 100 ppm or
0.01%. If we add jitter to oscillator drift, we have a total
frequency drift of 0.0132%. The total oscillator
frequency errors for common clock frequencies and bit
rates, including both drift and jitter, are shown in
Table 24-4.
TABLE 24-3: FREQUENCY ERROR FROM JITTER AT VARIOUS PLL-GENERATED CLOCK SPEEDS
Frequency Error at Various Nominal Bit Times (Bit Rates)
PLL
Pjitter
Tjitter
8 μs
(125 Kb/s)
4 μs
(250 Kb/s)
2 μs
(500 Kb/s)
1 μs
(1 Mb/s)
Output
40 MHz
24 MHz
16 MHz
0.5 ns
0.83 ns
1.25 ns
1 ns
0.00125%
0.00209%
0.00313%
0.00250%
0.00418%
0.00625%
0.005%
0.008%
0.013%
0.01%
0.017%
0.025%
1.67 ns
2.5 ns
TABLE 24-4: TOTAL FREQUENCY ERROR AT VARIOUS PLL-GENERATED CLOCK SPEEDS
(100 PPM OSCILLATOR DRIFT, INCLUDING ERROR FROM JITTER)
Frequency Error at Various Nominal Bit Times (Bit Rates)
Nominal PLL Output
8 μs
4 μs
2 μs
1 μs
(125 Kb/s)
(250 Kb/s)
(500 Kb/s)
(1 Mb/s)
40 MHz
24 MHz
16 MHz
0.01125%
0.01209%
0.01313%
0.01250%
0.01418%
0.01625%
0.015%
0.018%
0.023%
0.02%
0.027%
0.035%
