PIC18F2480/2580/4480/4580
REGISTER 24-1: CANCON: CAN CONTROL REGISTER
R/W-1
R/W-0
R/W-0
R/S-0
ABAT
R/W-0
WIN2
R/W-0
WIN1
R/W-0
WIN0
U-0
—
Mode 0
Mode 1
Mode 2
REQOP2
REQOP1
REQOP0
R/W-1
R/W-0
R/W-0
R/S-0
ABAT
U0
—
U-0
—
U-0
—
U-0
—
REQOP2
REQOP1
REQOP0
R/W-1
R/W-0
R/W-0
R/S-0
ABAT
R-0
R-0
R-0
R-0
REQOP2
REQOP1
REQOP0
FP3
FP2
FP1
FP0
bit 7
bit 0
Legend:
S = Settable bit
R = Readable bit
-n = Value at POR
W = Writable bit
‘1’ = Bit is set
U = Unimplemented bit, read as ‘0’
‘0’ = Bit is cleared x = Bit is unknown
bit 7-5
REQOP<2:0>: Request CAN Operation Mode bits
1xx= Request Configuration mode
011= Request Listen Only mode
010= Request Loopback mode
001= Disabled/Sleep mode
000= Request Normal mode
bit 4
ABAT: Abort All Pending Transmissions bit
1= Abort all pending transmissions (in all transmit buffers)(1)
0= Transmissions proceeding as normal
bit 3-1
Mode 0:
WIN<2:0>: Window Address bits
These bits select which of the CAN buffers to switch into the Access Bank area. This allows access to the
buffer registers from any data memory bank. After a frame has caused an interrupt, the ICODE<3:0> bits
can be copied to the WIN<2:0> bits to select the correct buffer. See Example 24-2 for a code example.
111= Receive Buffer 0
110= Receive Buffer 0
101= Receive Buffer 1
100= Transmit Buffer 0
011= Transmit Buffer 1
010= Transmit Buffer 2
001= Receive Buffer 0
000= Receive Buffer 0
bit 0
Unimplemented: Read as ‘0’
bit 4-0
Mode 1:
Unimplemented: Read as ‘0’
Mode 2:
FP<3:0>: FIFO Read Pointer bits
These bits point to the message buffer to be read.
0000= Receive Message Buffer 0
0001= Receive Message Buffer 1
0010= Receive Message Buffer 2
0011= Receive Message Buffer 3
0100= Receive Message Buffer 4
0101= Receive Message Buffer 5
0110= Receive Message Buffer 6
0111= Receive Message Buffer 7
1000:1111Reserved
Note 1: This bit will clear when all transmissions are aborted.
DS39637D-page 282
© 2009 Microchip Technology Inc.
