PIC18CXX2
GOTO
Unconditional Branch
INCF
Increment f
Syntax:
[ label ] GOTO k
0 ≤ k ≤ 1048575
k → PC<20:1>
None
Syntax:
Operands:
[ label ] INCF f,d,a
Operands:
Operation:
Status Affected:
0 ≤ f ≤ 255
d
a
[0,1]
[0,1]
Operation:
(f) + 1 → dest
Encoding:
1st word (k<7:0>)
2nd word(k<19:8>)
Status Affected:
Encoding:
C,DC,N,OV,Z
1110
1111
1111
k kkk
kkkk
kkkk
7
0
8
k
kkk kkkk
0010
10da
ffff
ffff
19
Description:
GOTOallows an unconditional
Description:
The contents of register ’f’ are
branch anywhere within entire 2M
byte memory range. The 20-bit
value ’k’ is loaded into PC<20:1>.
GOTOis always a two-cycle instruc-
tion.
incremented. If ’d’ is 0, the result is
placed in WREG. If ’d’ is 1, the
result is placed back in register ’f’
(default). If ’a’ is 0, the Access
Bank will be selected, overriding
the BSR value. If ’a’ = 1, then the
bank will be selected as per the
BSR value (default).
Words:
Cycles:
2
2
Q Cycle Activity:
Q1
Words:
Cycles:
1
1
Q2
Q3
Q4
Decode
Read literal
’k’<7:0>,
No
operation
Read literal
’k’<19:8>,
Write to PC
Q Cycle Activity:
Q1
Q2
Q3
Q4
No
operation
No
operation
No
operation
No
operation
Decode
Read
register ’f’
Process
Data
Write to
destination
GOTO THERE
Example:
INCF
CNT, 1, 0
Example:
After Instruction
Before Instruction
PC
=
Address (THERE)
CNT
=
0xFF
Z
=
=
=
0
?
?
C
DC
After Instruction
CNT
=
=
=
=
0x00
Z
1
1
1
C
DC
