PIC18CXX2
Register 14-2: SSPCON1: MSSP Control Register1
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
R/W-0
SSPM1
R/W-0
WCOL
SSPOV
SSPEN
CKP
SSPM3
SSPM2
SSPM0
bit 7
bit 0
bit 7
WCOL: Write Collision Detect bit
Master Mode:
2
1= A write to the SSPBUF register was attempted while the I C conditions were not valid for a transmission
to be started
0= No collision
Slave Mode:
1= The SSPBUF register is written while it is still transmitting the previous word must be cleared in software)
0= No collision
bit 6
SSPOV: Receive Overflow Indicator bit
In SPI mode:
1= A new byte is received while the SSPBUF register is still holding the previous data. In case of overflow,
the data in SSPSR is lost. Overflow can only occur in slave mode. In slave mode the user must read the
SSPBUF, even if only transmitting data, to avoid setting overflow. In master mode the overflow bit is not
set since each new reception (and transmission) is initiated by writing to the SSPBUF register. (Must be
cleared in software)
0= No overflow
2
In I C mode:
1= A byte is received while the SSPBUF register is still holding the previous byte. SSPOV is a "don’t care"
in transmit mode. (Must be cleared in software)
0= No overflow
bit 5
SSPEN: Synchronous Serial Port Enable bit
In both modes, when enabled, these pins must be properly configured as input or output.
In SPI mode:
1= Enables serial port and configures SCK, SDO, SDI, and SS as the source of the serial port pins
0= Disables serial port and configures these pins as I/O port pins
2
In I C mode:
1= Enables the serial port and configures the SDA and SCL pins as the source of the serial port pins
0= Disables serial port and configures these pins as I/O port pins
bit 4
CKP: Clock Polarity Select bit
In SPI mode:
1= Idle state for clock is a high level
0= Idle state for clock is a low level
2
In I C slave mode:
SCK release control
1= Enable clock
0= Holds clock low (clock stretch) (Used to ensure data setup time)
2
In I C master mode
Unused in this mode
bit 3 - 0
SSPM3:SSPM0: Synchronous Serial Port Mode Select bits
0000= SPI master mode, clock = FOSC/4
0001= SPI master mode, clock = FOSC/16
0010= SPI master mode, clock = FOSC/64
0011= SPI master mode, clock = TMR2 output/2
0100= SPI slave mode, clock = SCK pin. SS pin control enabled.
0101= SPI slave mode, clock = SCK pin. SS pin control disabled. SS can be used as I/O pin
2
0110= I C slave mode, 7-bit address
2
0111= I C slave mode, 10-bit address
2
1000= I C master mode, clock = FOSC / (4 * (SSPADD+1) )
1001= Reserved
1010= Reserved
2
1011= I C firmware controlled Master mode (Slave idle)
1100= Reserved
1101= Reserved
2
1110= I C slave mode, 7-bit address with start and stop bit interrupts enabled
2
1111= I C slave mode, 10-bit address with start and stop bit interrupts enabled
Legend:
R = Readable bit
W = Writable bit
’1’ = Bit is set
U = Unimplemented bit, read as ‘0’
’0’ = Bit is cleared x = Bit is unknown
- n = Value at POR reset
7/99 Microchip Technology Inc.
Preliminary
DS39026B-page 119
