PIC16F/LF1946/47
TABLE 29-12: USART SYNCHRONOUS TRANSMISSION REQUIREMENTS
Standard Operating Conditions (unless otherwise stated)
Operating Temperature
-40°C TA +125°C
Param.
Symbol
No.
Characteristic
Min.
Max.
Units Conditions
US120 TCKH2DTV SYNC XMIT (Master and Slave)
Clock high to data-out valid
3.0-5.5V
1.8-5.5V
3.0-5.5V
1.8-5.5V
3.0-5.5V
1.8-5.5V
—
—
—
—
—
—
80
100
45
ns
ns
ns
ns
ns
ns
US121 TCKRF
Clock out rise time and fall time
(Master mode)
50
US122 TDTRF
Data-out rise time and fall time
45
50
FIGURE 29-15:
USART SYNCHRONOUS RECEIVE (MASTER/SLAVE) TIMING
CK
DT
US125
US126
Note: Refer to Figure 29-5 for load conditions.
TABLE 29-13: USART SYNCHRONOUS RECEIVE REQUIREMENTS
Standard Operating Conditions (unless otherwise stated)
Operating Temperature
-40°C TA +125°C
Param.
Symbol
No.
Characteristic
Min.
Max. Units
Conditions
US125 TDTV2CKL SYNC RCV (Master and Slave)
Data-hold before CK (DT hold time)
10
15
—
—
ns
ns
US126 TCKL2DTL Data-hold after CK (DT hold time)
DS41414A-page 406
Preliminary
2010 Microchip Technology Inc.
