PIC16F/LF1946/47
DECFSZ
Decrement f, Skip if 0
INCFSZ
Increment f, Skip if 0
Syntax:
[ label ] DECFSZ f,d
Syntax:
[ label ] INCFSZ f,d
Operands:
0 f 127
d [0,1]
Operands:
0 f 127
d [0,1]
Operation:
(f) - 1 (destination);
skip if result = 0
Operation:
(f) + 1 (destination),
skip if result = 0
Status Affected:
Description:
None
Status Affected:
Description:
None
The contents of register ‘f’ are decre-
mented. If ‘d’ is ‘0’, the result is placed
in the W register. If ‘d’ is ‘1’, the result
is placed back in register ‘f’.
The contents of register ‘f’ are incre-
mented. If ‘d’ is ‘0’, the result is placed
in the W register. If ‘d’ is ‘1’, the result
is placed back in register ‘f’.
If the result is ‘1’, the next instruction is
executed. If the result is ‘0’, then a
NOPis executed instead, making it a
2-cycle instruction.
If the result is ‘1’, the next instruction is
executed. If the result is ‘0’, a NOPis
executed instead, making it a 2-cycle
instruction.
GOTO
Unconditional Branch
IORLW
Inclusive OR literal with W
Syntax:
[ label ] GOTO
0 k 2047
k
Syntax:
[ label ] IORLW
0 k 255
(W) .OR. k (W)
Z
k
Operands:
Operation:
Operands:
Operation:
Status Affected:
Description:
k PC<10:0>
PCLATH<4:3> PC<12:11>
Status Affected:
Description:
None
The contents of the W register are
OR’ed with the eight-bit literal ‘k’. The
result is placed in the W register.
GOTOis an unconditional branch. The
eleven-bit immediate value is loaded
into PC bits <10:0>. The upper bits of
PC are loaded from PCLATH<4:3>.
GOTOis a two-cycle instruction.
INCF
Increment f
IORWF
Inclusive OR W with f
Syntax:
[ label ] INCF f,d
Syntax:
[ label ] IORWF f,d
Operands:
0 f 127
d [0,1]
Operands:
0 f 127
d [0,1]
Operation:
(f) + 1 (destination)
Operation:
(W) .OR. (f) (destination)
Status Affected:
Description:
Z
Status Affected:
Description:
Z
The contents of register ‘f’ are incre-
mented. If ‘d’ is ‘0’, the result is placed
in the W register. If ‘d’ is ‘1’, the result
is placed back in register ‘f’.
Inclusive OR the W register with regis-
ter ‘f’. If ‘d’ is ‘0’, the result is placed in
the W register. If ‘d’ is ‘1’, the result is
placed back in register ‘f’.
DS41414A-page 374
Preliminary
2010 Microchip Technology Inc.
