PIC16F/LF1946/47
NOP
No Operation
MOVWI
Move W to INDFn
Syntax:
[ label ] NOP
Syntax:
[ label ] MOVWI ++FSRn
[ label ] MOVWI --FSRn
[ label ] MOVWI FSRn++
[ label ] MOVWI FSRn--
[ label ] MOVWI k[FSRn]
Operands:
Operation:
Status Affected:
Description:
Words:
None
No operation
None
No operation.
Operands:
Operation:
n [0,1]
-32 k 31
If not present, k = 0.
1
Cycles:
1
W INDFn
Effective address is determined by
Example:
NOP
•
•
•
FSR + 1 (preincrement)
FSR - 1 (predecrement)
FSR + k (relative offset)
After the Move, the FSR value will be
either:
Load OPTION_REG Register
with W
OPTION
•
•
FSR + 1 (all increments)
FSR - 1 (all decrements)
Syntax:
[ label ] OPTION
None
Unchanged
Operands:
Operation:
Status Affected:
Description:
Status Affected:
None
(W) OPTION_REG
None
Mode
Syntax
Move data from W register to
OPTION_REG register.
Preincrement
Predecrement
Postincrement
Postdecrement
++FSRn
--FSRn
FSRFn++
FSRn--
RESET
Software Reset
Syntax:
[ label ] RESET
Description:
This instruction is used to move data
between W and one of the indirect
registers (INDFn). Before/after this
move, the pointer (FSRn) is updated by
pre/post incrementing/decrementing it.
Operands:
Operation:
None
Execute a device Reset. Resets the
nRI flag of the PCON register.
Status Affected:
Description:
None
Note: The INDFn registers are not
physical registers. Any instruction that
accesses an INDFn register actually
accesses the register at the address
specified by the FSRn.
This instruction provides a way to
execute a hardware Reset by soft-
ware.
FSRn is limited to the range 0000h -
FFFFh. Incrementing/decrementing it
beyond these bounds will cause it to wrap
around.
The increment/decrement operation on
FSRn WILL NOT affect any Status bits.
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 377
