PIC16F/LF1946/47
CALL
Call Subroutine
CLRWDT
Clear Watchdog Timer
Syntax:
[ label ] CALL
0 k 2047
k
Syntax:
[ label ] CLRWDT
Operands:
Operation:
Operands:
Operation:
None
(PC)+ 1 TOS,
k PC<10:0>,
(PCLATH<4:3>) PC<12:11>
00h WDT
0 WDT prescaler,
1 TO
1 PD
Status Affected:
Description:
None
Status Affected:
Description:
TO, PD
Call Subroutine. First, return address
(PC + 1) is pushed onto the stack.
The eleven-bit immediate address is
loaded into PC bits <10:0>. The upper
bits of the PC are loaded from
PCLATH. CALLis a two-cycle instruc-
tion.
CLRWDTinstruction resets the Watch-
dog Timer. It also resets the prescaler
of the WDT.
Status bits TO and PD are set.
COMF
Complement f
CALLW
Subroutine Call With W
Syntax:
[ label ] COMF f,d
Syntax:
[ label ] CALLW
Operands:
0 f 127
d [0,1]
Operands:
Operation:
None
(PC) +1 TOS,
(W) PC<7:0>,
Operation:
(f) (destination)
(PCLATH<6:0>) PC<14:8>
Status Affected:
Description:
Z
The contents of register ‘f’ are com-
plemented. If ‘d’ is ‘0’, the result is
stored in W. If ‘d’ is ‘1’, the result is
stored back in register ‘f’.
Status Affected:
Description:
None
Subroutine call with W. First, the
return address (PC + 1) is pushed
onto the return stack. Then, the con-
tents of W is loaded into PC<7:0>,
and the contents of PCLATH into
PC<14:8>. CALLWis a two-cycle
instruction.
DECF
Decrement f
CLRF
Clear f
Syntax:
[ label ] DECF f,d
Syntax:
[ label ] CLRF
0 f 127
f
Operands:
0 f 127
d [0,1]
Operands:
Operation:
00h (f)
1 Z
Operation:
(f) - 1 (destination)
Status Affected:
Description:
Z
Status Affected:
Description:
Z
Decrement register ‘f’. If ‘d’ is ‘0’, the
result is stored in the W
The contents of register ‘f’ are cleared
and the Z bit is set.
register. If ‘d’ is ‘1’, the result is stored
back in register ‘f’.
CLRW
Clear W
Syntax:
[ label ] CLRW
Operands:
Operation:
None
00h (W)
1 Z
Status Affected:
Description:
Z
W register is cleared. Zero bit (Z) is
set.
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 373
