PIC16F/LF1946/47
REGISTER 26-5: LCDSEn: LCD SEGMENT ENABLE REGISTERS
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
R/W-0/0
SEn
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
x = Bit is unknown
‘0’ = Bit is cleared
bit 7-0
SEn: Segment Enable bits
1= Segment function of the pin is enabled
0= I/O function of the pin is enabled
REGISTER 26-6: LCDDATAn: LCD DATA REGISTERS
R/W-x/u R/W-x/u R/W-x/u R/W-x/u R/W-x/u
SEGx-COMy SEGx-COMy SEGx-COMy SEGx-COMy SEGx-COMy SEGx-COMy SEGx-COMy SEGx-COMy
R/W-x/u
R/W-x/u
R/W-x/u
bit 7
bit 0
Legend:
R = Readable bit
u = Bit is unchanged
‘1’ = Bit is set
W = Writable bit
x = Bit is unknown
‘0’ = Bit is cleared
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
bit 7-0
SEGx-COMy: Pixel On bits
1= Pixel on (dark)
0= Pixel off (clear)
