PIC16F/LF1946/47
REGISTER 12-13: PORTD: PORTD REGISTER
R/W-x/u
RD7
R/W-x/u
RD6
R/W-x/u
RD5
R/W-x/u
RD4
R/W-x/u
RD3
R/W-x/u
RD2
R/W-x/u
RD1
R/W-x/u
RD0
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
x = Bit is unknown
‘0’ = Bit is cleared
bit 7-0
RD<7:0>: PORTD General Purpose I/O Pin bits
1= Port pin is > VIH
0= Port pin is < VIL
REGISTER 12-14: TRISD: PORTD TRI-STATE REGISTER
R/W-1/1
TRISD7
R/W-1/1
TRISD6
R/W-1/1
TRISD5
R/W-1/1
TRISD4
R/W-1/1
TRISD3
R/W-1/1
TRISD2
R/W-1/1
TRISD1
R/W-1/1
TRISD0
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
x = Bit is unknown
‘0’ = Bit is cleared
bit 7-0
TRISD<7:0>: PORTD Tri-State Control bits
1= PORTD pin configured as an input (tri-stated)
0= PORTD pin configured as an output
REGISTER 12-15: LATD: PORTD DATA LATCH REGISTER
R/W-x/u
LATD7
R/W-x/u
LATD6
R/W-x/u
LATD5
R/W-x/u
LATD4
R/W-x/u
LATD3
R/W-x/u
LATD2
R/W-x/u
LATD1
R/W-x/u
LATD0
bit 7
bit 0
Legend:
R = Readable bit
W = Writable bit
U = Unimplemented bit, read as ‘0’
-n/n = Value at POR and BOR/Value at all other Resets
u = Bit is unchanged
‘1’ = Bit is set
x = Bit is unknown
‘0’ = Bit is cleared
bit 7-0
LATD<7:0>: PORTD Output Latch Value bits(1)
Note 1: Writes to PORTD are actually written to corresponding LATD register. Reads from PORTD register is
return of actual I/O pin values.
2010 Microchip Technology Inc.
Preliminary
DS41414A-page 133
