PIC12(L)F1501
27.2 DC Characteristics: PIC12(L)F1501-I/E (Industrial, Extended) (Continued)
Standard Operating Conditions (unless otherwise stated)
PIC12LF1501
PIC12F1501
Operating temperature
-40°C TA +85°C for industrial
-40°C TA +125°C for extended
Standard Operating Conditions (unless otherwise stated)
Operating temperature
-40°C TA +85°C for industrial
-40°C TA +125°C for extended
Conditions
Param
No.
Device
Characteristics
Min.
Typ†
Max.
Units
VDD
Note
(1, 2)
Supply Current (IDD)
D019B
—
—
—
34
37
210
270
—
A
A
mA
3.0
5.0
3.0
FOSC = 500 kHz
ECM mode
D019C
D019C
0.65
FOSC = 20 MHz
ECH mode
—
—
0.75
0.87
—
—
mA
mA
3.0
5.0
FOSC = 20 MHz
ECH mode
*
These parameters are characterized but not tested.
†
Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are not
tested.
Note 1: The test conditions for all IDD measurements in active operation mode are: CLKIN = external square wave, from
rail-to-rail; all I/O pins tri-stated, pulled to VDD; MCLR = VDD; WDT disabled.
2: The supply current is mainly a function of the operating voltage and frequency. Other factors, such as I/O pin loading
and switching rate, oscillator type, internal code execution pattern and temperature, also have an impact on the current
consumption.
DS41615A-page 230
Preliminary
2011 Microchip Technology Inc.
