PIC12(L)F1501
FIGURE 27-1:
PIC12F1501 VOLTAGE FREQUENCY GRAPH, -40°C TA +125°C
5.5
2.5
2.3
0
4
10
16
20
Frequency (MHz)
Note 1: The shaded region indicates the permissible combinations of voltage and frequency.
2: Refer to Table 27-1 for each Oscillator mode’s supported frequencies.
FIGURE 27-2:
PIC12LF1501 VOLTAGE FREQUENCY GRAPH, -40°C TA +125°C
3.6
2.5
1.8
0
4
10
16
20
Frequency (MHz)
Note 1: The shaded region indicates the permissible combinations of voltage and frequency.
2: Refer to Table 27-1 for each Oscillator mode’s supported frequencies.
