PIC12(L)F1501
27.1 DC Characteristics: PIC12(L)F1501-I/E (Industrial, Extended)
Standard Operating Conditions (unless otherwise stated)
PIC12LF1501
Operating temperature
-40°C TA +85°C for industrial
-40°C TA +125°C for extended
Standard Operating Conditions (unless otherwise stated)
PIC12F1501
Operating temperature
-40°C TA +85°C for industrial
-40°C TA +125°C for extended
Param.
No.
Sym.
Characteristic
Supply Voltage
Min. Typ† Max.
Units
Conditions
D001
VDD
PIC12LF1501 1.8
3.6
3.6
V
V
FOSC 16 MHz:
FOSC 20 MHz
2.5
D001
PIC12F1501 2.3
2.5
5.5
5.5
V
V
FOSC 16 MHz:
FOSC 20 MHz
D002*
VDR
RAM Data Retention Voltage(1)
PIC12LF1501 1.5
PIC12F1501 1.65
Power-on Reset Release Voltage
PIC12LF1501
PIC12F1501
Power-on Reset Rearm Voltage
V
V
Device in Sleep mode
Device in Sleep mode
D002*
D002A* VPOR*
1.6
1.7
V
V
D002A*
D002B* VPORR*
PIC12LF1501
PIC12F1501
0.8
1.7
V
V
D002B*
D003
VADFVR
Fixed Voltage Reference Voltage for
ADC, Initial Accuracy
1
1
1
1
1
1
%
1.024V, VDD 2.5V, 85°C (NOTE 2)
1.024V, VDD 2.5V, 125°C (NOTE 2)
2.048V, VDD 2.5V, 85°C
2.048V, VDD 2.5V, 125°C
4.096V, VDD 4.75V, 85°C
4.096V, VDD 4.75V, 125°C
D003C* TCVFVR
Temperature Coefficient, Fixed
Voltage Reference
-130
0.270
ppm/°C
%/V
D003D* VFVR/
VIN
Line Regulation, Fixed Voltage
Reference
D004*
SVDD
VDD Rise Rate to ensure internal
Power-on Reset signal
0.05
V/ms See Section 6.1 “Power-on Reset
(POR)” for details.
*
These parameters are characterized but not tested.
Data in “Typ” column is at 3.0V, 25°C unless otherwise stated. These parameters are for design guidance only and are not
tested.
Note 1: This is the limit to which VDD can be lowered in Sleep mode without losing RAM data.
2: For proper operation, the minimum value of the ADC positive voltage reference must be 1.8V or greater. When selecting the
FVR or the VREF+ pin as the source of the ADC positive voltage reference, be aware that the voltage must be 1.8V or
greater.
2011 Microchip Technology Inc.
Preliminary
DS41615A-page 227
