25AA512/25LC512
The Write Enable Latch (WEL) bit indicates the status
of the write enable latch and is read-only. When set to
a ‘1’, the latch allows writes to the array, when set to a
‘0’, the latch prohibits writes to the array. The state of
this bit can always be updated via the WREN or WRDI
commands regardless of the state of write protection
on the STATUS register. These commands are shown
in Figure 2-4 and Figure 2-5.
2.4
Read Status Register Instruction
(RDSR)
The Read Status Register instruction (RDSR) provides
access to the STATUS register. The STATUS register
may be read at any time, even during a write cycle. The
STATUS register is formatted as follows:
TABLE 2-2:
STATUS REGISTER
The Block Protection (BP0 and BP1) bits indicate
which blocks are currently write-protected. These bits
are set by the user issuing the WRSRinstruction. These
bits are nonvolatile, and are shown in Table 2-3.
7
6
–
X
5
–
X
4
–
X
3
2
1
0
W/R
W/R W/R
R
R
WPEN
BP1 BP0 WEL WIP
See Figure 2-6 for the RDSRtiming sequence.
W/R = writable/readable. R = read-only.
The Write-In-Process (WIP) bit indicates whether the
25XX512 is busy with a write operation. When set to a
‘1’, a write is in progress, when set to a ‘0’, no write is
in progress. This bit is read-only.
FIGURE 2-6:
READ STATUS REGISTER TIMING SEQUENCE (RDSR)
CS
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
SCK
SI
Instruction
0
0
0
0
0
1
0
1
Data from STATUS Register
High-Impedance
7
6
5
4
3
2
1
0
SO
© 2007 Microchip Technology Inc.
Preliminary
DS22021B-page 11
