PIC12CE67X
Standard Operating Conditions (unless otherwise specified)
Operating temperature
0˚C ≤ TA ≤ +70˚C (commercial)
–40˚C ≤ TA ≤ +85˚C (industrial)
–40°C ≤ TA ≤ +125˚C (extended)
DC CHARACTERISTICS
Operating voltage VDD range as described in DC spec Section 12.1 and
Section 12.2.
Param
No.
Characteristic
Output High Voltage
Sym
Min
Typ Max Units
†
Conditions
D090
I/O ports/CLKOUT (Note 3)
VOH VDD - 0.7
VDD - 0.7
-
-
-
-
-
-
-
-
V
V
V
V
IOH = -3.0 mA, VDD = 4.5V,
–40°C to +85°C
IOH = -2.5 mA, VDD = 4.5V,
–40°C to +125°C
IOH = -1.3 mA, VDD = 4.5V,
–40°C to +85°C
IOH = -1.0 mA, VDD = 4.5V,
–40°C to +125°C
D090A
D092
OSC2
VDD - 0.7
D092A
VDD - 0.7
Capacitive Loading Specs on
Output Pins
D100
OSC2 pin
COSC2
CIO
-
-
-
-
15
50
pF In XT, HS and LP modes when
external clock is used to drive
OSC1.
D101
†
All I/O pins and OSC2
pF
Data in “Typ” column is at 5V, 25°C unless otherwise stated. These parameters are for design guidance only
and are not tested.
Note 1: In EXTRC oscillator configuration, the OSC1/CLKIN pin is a Schmitt Trigger input. It is not recommended that
the PIC12C67X be driven with external clock in RC mode.
2: The leakage current on the MCLR pin is strongly dependent on the applied voltage level. The specified levels
represent normal operating conditions. Higher leakage current may be measured at different input voltages.
3: Negative current is defined as coming out of the pin.
4: Extended operating range is Advance Information for this device.
5: When configured as external reset, the input leakage current is the weak pulll-up current of -10mA minimum.
This pull-up is weaker than the standard I/O pull-up.
