71M6543F/H and 71M6543G/GH Data Sheet
Min Typ Max Unit
Parameter
Note:
Condition
1. Guaranteed by design; not production tested.
2. Unless stated otherwise, the following test conditions apply to all the parameters provided in
this table: FIR_LEN[1:0]=1, VREF_DIS=0, PLL_FAST=1, ADC_DIV=0, MUX_DIV=6, LSB values
do not include the 9-bit left shift at CE input.
6.4.16 Pre-Amplifier for IADC0-IADC1
Table 106: Pre-Amplifier Performance Specifications
PARAMETER
CONDITION
MIN TYP MAX
UNIT
TA= 5⁰C,
V3P3=3.3 V,
PRE_E=1,
FIR_LEN=2,
DIFF0_E=1,
2520Hz sample rate
V3P3 =
Differential Gain
Vin=30mV differential
Vin=15mV differential (see note 1)
7.8 7.92 8.0
7.8 7.92 8.0
V/V
V/V
Gain Variation vs V3P3
Vin=30mV differential (see note 1)
Gain Variation vs Temp
Vin=30mV differential (see note 1)
Phase Shift,
Vin=30mV differential (see note 1)
-100
10
100
-80
6
ppm/%
ppm/C
mº
2.97 V, 3.63 V
TA = -40⁰C, 85⁰C
-25
TA=25⁰C,
V3P3=3.3 V
-6
PRE_E=1,
Preamp input current
IADC0
IADC1
FIR_LEN=10,
DIFF0_E=1
2520Hz sample rate,
IADC0=IADC1=V3P3
TA=25⁰C,
4
4
9
9
16
16
uA
uA
V3P3=3.3 V,
PRE_E=1,
FIR_LEN=2,
Preamp+ADC THD
Vin=30mV differential
Vin=15mV differential
-82
-86
dB
dB
DIFF0_E=1,
2520Hz sample rate.
TA=25⁰C,
V3P3=3.3 V,
PRE_E=1,
FIR_LEN=10,
DIFF0_E=1,
2520Hz sample rate
Preamp Offset
IADC0=IADC1=V3P3+30mV
IADC0=IADC1= V3P3+15mV
IADC0=IADC1= V3P3
IADC0=IADC1= V3P3-15mV
IADC0=IADC1= V3P3-30mV
Note:
-0.63
-0.57
-0.56
-0.56
-0.55
mV
mV
mV
mV
mV
1. Guaranteed by design; not production tested.
v1.2
© 2008–2011 Teridian Semiconductor Corporation
145
