71M6543F/H and 71M6543G/GH Data Sheet
Name
Location Rst Wk Dir Description
This word describes the source of power and the status of the VDD.
Description
VSTAT[2:0]
000
System Power OK. V3P3A>3.0v. Analog modules are functional and
accurate. [V3AOK,V3OK]=11
001
010
011
System Power Low. 2.8v<V3P3A<3.0v. Analog modules not accurate.
Switch over to battery power is imminent. [V3AOK,V3OK]=01
Battery power and VDD OK. VDD>2.25v. Full digital functionality.
[V3AOK,V3OK]=00, [VDDOK,VDDgt2]=11
SFR F9[2:0]
VSTAT[2:0]
–
–
R
Battery power and VDD>2.0. Flash writes are inhibited. If the
TRIMVDD[5] fuse is blown, PLL_FAST is cleared.
[V3AOK,V3OK]=00, [VDDOK,VDDgt2]=01
101
Battery power and VDD<2.0. When VSTAT=101, processor is nearly
out of voltage. Processor failure is imminent.
[V3AOK,V3OK]=00, [VDDOK,VDDgt2]=00
Arms the WAKE timer and loads it with WAKE_TMR[7:0]. When SLEEP or LCD mode
is asserted by the MPU, the WAKE timer becomes active.
WAKE_ARM
WAKE_TMR
WD_RST
28B2[5]
2880[7:0]
28B4[7]
0
0
0
–
–
0
R/W
R/W Timer duration is WAKE_TMR+1 seconds.
Reset the WD timer. The WD is reset when a 1 is written to this bit. Writing a one
clears and restarts the watch dog timer.
W
DIO4 wake flag bit. If DIO4 is configured to wake the part, this bit is set whenever the
WF_DIO4
de-bounced version of DIO4 rises. It is held in reset if DI04 is not configured for
28B1[2]
0
–
R
wakeup.
DIO52 wake flag bit. If DIO52 is configured to wake the part, this bit is set whenever the
de-bounced version of DIO52 rises. It is held in reset if DI052 is not configured for wakeup.
WF_DIO52
WF_DIO55
28B1[1]
28B1[0]
0
0
–
–
R
R
DIO55 wake flag bit. If DIO55 is configured to wake the part, this bit is set whenever the
de-bounced version of DIO55 rises. It is held in reset if DI055 is not configured for wakeup.
WF_TMR
WF_PB
WF_RX
28B1[5]
28B1[3]
28B1[4]
0
0
0
–
–
–
R
R
R
Indicates that the wake timer caused the part to wake up.
Indicates that the PB caused the part to wake.
Indicates that RX caused the part to wake.
WF_CSTART
WF_RST
WF_RSTBIT
WF_OVF
WF_ERST
WF_BADVDD
28B0[7]
28B0[6]
28B0[5]
28B0[4]
28B0[3]
28B0[2]
0
1
0
0
0
0
Indicates that the Reset pin, Reset bit, ERST pin, Watchdog timer, the cold start detector,
or bad VBAT caused the part to reset.
–
R
v1.2
© 2008–2011 Teridian Semiconductor Corporation
117
