Ribbon Cable Interconnect Solutions
Cable-to-Board Receptacle Connectors, Double Row, .050 x .050
[1.27 x 1.27] Centerline
A
Material and Finish
Housing — Thermoplastic, black,
94V-0 rated
Latch — Stainless steel
Contacts — Phosphor bronze; duplex
plated .000030 [0.00076] minimum
gold in mating area, .000150 [0.00381]
minimum tin on solder tail, with entire
contact underplated .000050 [0.00127]
minimum nickel
.280
[7.11]
.627
[15.94]
.690
[17.56]
Related Product Data
Mating Headers — pages 21 and 24
(latching)
D
Terminating Covers (Must be
Purchased Separately, 2 Required
per Connector) — page 27
.120
[3.05]
Termination Tooling — page 28
Performance Specifications —
page 29
.050
[1.27]
Typ
B Spaces at
.050 [1.27] = C
Technical Documents — page 29
Product Specification 108-1443
Application Specification
408-9817, 408-9909
.284 .327
[7.21] [8.31]
.050
[1.27]
Packaging — Tube
Receptacle
Dimensions
C
No. of
Pos.
Part Numbers
A
B
D
With Latch
Without Latch
5-104893-1
5-104893-2
5-104893-3
5-104893-4
5-104893-5
5-104893-6
5-104893-7
5-104893-8
6-104893-0
10
20
30
40
50
60
70
80
100
.578 [14.68]
.828 [21.03]
1.078 [27.38]
1.328 [33.73]
1.578 [40.08]
1.828 [46.43]
2.078 [52.78]
2.328 [59.13]
2.828 [71.83]
4
.200 [5.08]
.266 [6.76]
.516 [13.11]
.766 [19.46]
1.016 [25.81]
1.266 [32.16]
1.516 [38.51]
1.766 [44.86]
2.016 [51.21]
2.516 [63.91]
5-104892-1
5-104892-2
5-104892-3
5-104892-4
5-104892-5
5-104892-6
5-104892-7
5-104892-8
6-104892-0
9
.450 [11.43]
.700 [17.78]
.950 [24.13]
1.200 [30.48]
1.450 [36.83]
1.700 [43.18]
1.950 [49.53]
2.450 [62.23]
14
19
24
29
34
39
49
Note: All part numbers are RoHS compliant.
26
Catalog 82012
Revised 4-12
Dimensions are shown for
Dimensions are in inches
