Ribbon Cable Interconnect Solutions
Application Tooling for Cable Connectors
The Manual Miniature
Application Frame
Assembly 91295-1,
equipped with a Cover
Closing Kit 543518-1, is
used for the IDC termina-
tion of ribbon cable to the
cable connectors shown on
page 26.
Prior to termination, the
covers must be partially
assembled onto a connec-
tor housing, the cable
inserted between the cov-
ers and contacts and the
covers preclosed by hand,
clamping the cable in
place.
In the Manual Miniature
Application Frame
Assembly, the covers are
fully seated to complete the
mass termination and pro-
vide strain relief for the
completed connection.
Manual Miniature Application Frame Assembly 91295-1
with Cover Closing Kit 543518-1
For tooling information, call
Technical Support Center
1-800-522-6752.
Note: Refer to TE Instruction
Sheets 408-9817 (Frame Assembly
91295-1) and 408-9909 (Cover
Closing Kit 543518-1) for complete
termination/tooling information.
Note: All part numbers are RoHS compliant.
