NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
Protective Hardware
Pin Hoods, Internal
Open-End and Closed-
End
C
C
Material and Finish
See charts
A
A
Pin Hoods are used to
protect pin contacts that
protrude from a connector
housing.
B
B
When contacts are mixed
(pins and sockets in both
housings), an Internal Pin
Hood is used on one housing
and an External Pin Hood
(page 83) is used on the
other housing. Or a Long
Shield is used on one housing
and an External Pin Hood
must be used on the other
housing. When a housing is
loaded with all pin contacts,
an Internal or External Pin
Hood may be used—no Pin
Hood is required on the mat-
ing half.
Internal Open-End
Internal Closed-End
Note: Typical Internal Open-End and Closed-End Pin Hoods are illustrated. Slight differences in configu-
ration exist for various sizes. The mounting holes and/or slots in each Pin Hood match the
mounting hole pattern of the connector housing on which the Pin Hood is used.
Pin Hoods, Internal Open-End
Connectors Used On (No. of Positions)
Dimensions
B
Special Application
Pin Hood
Part No.
Material
Standard Posted
A
C
High
Current
High
Mixed
—
Voltage
External Open-End Pin
1.000 .500 .718
25.4 12.7 18.24
Nickel Plated
Steel
204258-6
201363-4
201785-4
201786-4
6
14
6
14
—
—
Hoods with flanges (page 83)
are used primarily for mount-
ing a connector with pin
contacts to a panel.
1.250 .550 .718
31.75 13.97 18.24
1.632 .725 .718
41.45 18.42 18.24
2.000 .880 .718
50.8 22.35 18.24
Nickel Plated
Steel
—
—
—
—
—
—
Nickel Plated
Steel
26
34
26
34
15
Nickel Plated
Steel
All Pin Hoods may be
16
20
secured to connector hous-
ings using other appropriate
hardware, such as Jackscrews
and Guide Pins and Sockets.
Pin Hoods, Internal Closed-End
Connectors Used On (No. of Positions)
Special Application
Dimensions
Material
Pin Hood
Part No.
Standard Posted
A
B
C
High
High
Mixed
16
Current
Voltage
2.130 .880 .687
54.1 22.35 17.45
Nickel Plated
Steel
202434-4
202394-2
201369-4
201364-4
34
50
34
50
—
—
12
—
—
20
—
2.875 .952 .687
73.02 24.18 17.45
Nickel Plated
Steel
42
—
2.765 1.310 .687
70.23 33.27 17.45
Nickel Plated
Steel
75
75
28
—
2.975 1.740 .687
75.57 44.2 17.45
Nickel Plated
Steel
104
104
—
2.975 2.040 .687
75.57 51.82 17.45
Nickel Plated
Steel
203743-4 CF160 CF CF160 CF
—
—
82
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
www.tycoelectronics.com equivalent U.S. Customary Units. to change.
Dimensions are shown for USA: 1-800-522-6752
reference purposes only. Canada: 1-905-470-4425
South America: 55-11-3611-1514
Hong Kong: 852-2735-1628
Japan: 81-44-844-8013
Specifications subject
Mexico: 01-800-733-8926
C. America: 52-55-5-729-0425 UK: 44-141-810-8967
