NOTE: All part numbers
are RoHS Compliant
AMP M Series
Pin and Socket Connectors
M Series V.35 Cable Connectors
Cable Connector Kits,
34 Position, Phenolic
2.050±.030
[52.07±0.76
]
Plug
.828±.030
±.0400
A
[±1.02]
[21.03±0.76
]
1.620±.040
[41.15±1.02
]
Receptacle
Material and Finish
Housing - Flame retardant
phenolic, black
Shield - Anodized aluminum
Screws - Steel, zinc plated
Jackscrews - Stainless steel
Cable Clamp - Steel, nickel
plated
Notes:
1. Plug and receptacle connector kits come partially assembled.
2. Plug connector kits are
Kits include:
available with long and short shields, (long shield provides pin protection) and two differ-
ent size cable clamps.
ꢀHousing
3. Housings are keyed to fix the proper location of the male and female jackscrew as defined
ꢀOne-piece shield
ꢀOne-piece turnable
jackscrews
ꢀStrain relief clamp
ꢀMounting screws
by 408-2593.
4. Short shield kits, Part No. 213753-1 available with all accessories listed above except hous-
ing block and jackscrews. Part number for blocks are found on page 47.
5. Pin and socket contacts sold separately. Size 16, Type III+ contacts are listed on page 31.
Kit Part Numbers
Shield
Size
Cable Dia.
Range
Housing
Material
Dimension
A
Receptacle
Plug
.435-.545
1.53
Short
Short
Long
Long
Short
Short
Short
Phenolic
Phenolic
Phenolic
Phenolic
Phenolic
Phenolic
Phenolic
—
213300-1
11.05-13.83
38.86
.300-.450
7.62-11.43
.435-.545
11.05-13.83
.300-.450
7.62-11.43
.435-.545
11.05-13.83
.300-.450
7.62-11.43
.200-.300
5.08-7.62
1.53
38.86
1.97
50.04
1.97
50.04
1.53
38.86
1.53
38.86
1.53
38.86
—
213300-2
213300-3
213300-4
—
—
—
213522-1
213522-2
—
—
213300-7
68
Catalog 82003
Revised 06-08
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets are
